KANEBO HITECLOTH Cleaning Wiper
KANEBO HITECLOTH Cleaning Wiper
High technology fields are growing every day in sophistication and precision. Highly efficient wiping cloths are essential for a strict dust-free environment in the manufacturing of such products as LSIs and LCDs. Savina MX was created to readily meet the needs of the times, with excellent functions enough to cope with the ultimate dust-free condition in super clean rooms.
Wipers for use in clean rooms should clean all instruments, apparatuses and peripheral devices while causing no contamination. They are also required to absorb and remove any undesired moisture. Savina MX, which contains all properties needed for such wipers, is one of the highest-performance wiping cloths designed for the age of high technology.
Super High-Shrinkage, High-Density Finish
Cross section of Savina MX
Surface of Savina MX
After knitting on a special high gauge knitting machine, the greige for Savina MX is shrunken both lengthwise and widthwise to as much as 40% of its original dimension. It is not treated with binders of any kind to achieve such a dense construction. The resultant wiping cloth has as high a surface area as 25,700 c㎡/g, thus ensuring dust removal without releasing any lint. Conventional wiping cloths have a surface area of only 2,420 c㎡/g.
Features
- Generates only a minuscule amount of lint.
- Absorbs and retains water quickly and positively.
- Has lower dissolution of residual ions and other substances.
- Provides high wiper performance (removes a maximum amount of dust without contaminating the clean room equipment).
Applications
- Production processes for photomagnetic disks, hard disks and floppy disks
- Production processes for deflection plates of liquid crystals and other items
- Compact and magnetic disk production processes
- Video deck production processes
- Contact lens production processes
- Camera assembly lines
- Printed circuit board cleaning processes
- Cleaning processes for camera lenses before coating
- Medicine production line cleaning processes
- Movie film cleaning process
- Production processes for semiconductors and integrated circuits
- Workpiece cleaning process before precision coating
